Kiloview N40 (UHD HDMI NDI Bi-Directional Video Encoder/Decoder)

Kiloview N40 for NDI 4K HDMI 2.0 NDI Encoder/Decoder

Kiloview N40 for NDI supports up to UHD 4Kp60 video input (Encoder) or 4Kp60 video output (Decoder). This converter is small and compact enough to put in your pocket with the overall size of 100*80*24mm. It features an HDMI2.0 input and HDMI2.0 loop through for view on the monitor while NDI streaming, or HDMI 2.0 output while decoding. A tally system with a big tally light is built-in for indicating which camera is in program or preview. It also has the 3.5mm audio input/output which supports intercom (a Kiloview software required).

Kiloview N40 for NDI has a wide DC input range from 5V to 18V, so it can be easily powered by USB, power bank or camera battery, it can also be powered over Ethernet (PoE). A threaded screw camera mount is provided for your mounting on a camera. PTZ interface by USB adapter is supported.

The N40 for NDI is also compatible with Kiloview IMS software to help with the device management, NDI source management, remote configuration and upgrading, etc..

Product Highlights

• 1 x HDMI input, 1 x HDMI loop-through or decoding output; HDMI video input/output with embedded audio.
• Wide DC power input range from 5V-18V to make it easy powered by USB, power bank, etc.
• 3.5mm audio Input/output and Intercom supported.（Kiloview Software required）
• Bi-directional converting, up to 4Kp60 NDI encoding/decoding (self-defined) supported.
• Compatible with Kiloview IMS software for device and source management.
• Optional control cable supported which can control PTZ over Visca / Visca over IP / Pelco etc..(Customize available for other unlisted PTZ protocols)
